STUDER Innotec
Xtender
User manual V.3.1.0 45
XTM model 1500-12 2000-12 2400-24 3500-24 2600-48 4000-48
General data
Auxiliary contacts
2 independent contacts 16 A - 250 Vac (potential-free 3 points)
****2 independent contacts 16 A - 140 Vac (potential-free 3 points)
Maximum transfer relay
current
50A
Maximum transfer time 0-15ms (UPS mode)
Weight 15kg 18.5kg 16.2kg 21.2kg 16.2kg 22.9kg
Dimensions: H x W x D [mm] 230x300x500
Protection degree IP20
Conformity EN 61000-6-1, EN 61000-6-3, EN 55014, EN 55022, EN 61000-3-2, Dir.
89/336/EEC, LVD 73/23/EEC
Operating temperature
range
-20 to 55°C
Ventilation Forced from 45 °C
Noise level <40 dB / <45 dB (without / with ventilation)
Warranty 2 years
Options
Remote control and programming centre for wall mounting: RCC-02
Remote control and programming centre for panel mounting: RCC-03
Battery temperature sensor: BTS-01
Communication cable for 3ph and // (CAB-RJ45-8-2)
Remote command Modul (DIN rail mounting): RCM-10
