FACTS & FIGURES
TECHNICAL SPECIFICATION
Input Gain Min Max Range
Mic (to L/R) 2dB 60dB 48dB
Line (to L/R) -8dB 40dB 48dB
Stereo Line (to L/R) 0dB 12dB 12dB
Equalisation (all +/-15dB) Lo Mid Hi
Mic Channels 60Hz 250Hz-6kHz 12kHz
Stereo Input 45Hz - 12kHz
Frequency Response (any Input) 10Hz - 45kHz +/-0.5dB
Distortion (any Input) 0.03%
Noise
Mic EIN -128dBu
Signal to noise ratio >85dB (unweighted) with typical control settings
Dynamic range >108dB
DSP
Reverb mode 3 Vocal, 1 ADT, 2 Reverb
Delay mode 6 settings between 100ms and 720ms
Metering Peak reading 12 segment 3 colour LED bargraphs
Maximum Input Level At Max gain At Min gain
Mic -38dBu +10dBu
Line -21dBu +28dBu
Stereo Line +10dBu +22dBu
Aux Input +16dBu +22dBu
Output Levels Nominal Maximum Impedance
Mono Insert +4dBu +22dBu <22 ohms
Aux Sends 1/2 - +22dBu 100 ohms
L/R Outputs +4dBu +28dBu 75 ohms
L/R Insert -2dBu +22dBu <22 ohms
Phones - +22dBu 33 ohms
Power Supply
230V range +/-10%, ~50/60Hz, 150mA Max
115V range +/-10%, ~50/60Hz, 300mA Max
Dimensions
Width 482mm (19")
Height 266mm (10.5") when racked, the unit occupies 6 rack spaces (6U)
Depth 120mm (4.8")
Weight
Net 7kg (15.4lbs)
Shipping 8.2kg (18.1lbs)
