Studiomaster AC36II - Extend Remote Control Protocol Connection

13
1, Control package Format
2, Command Detail
(1) Gain Control(0x41)
Example (increase input channel 1 gain): 7B7D01410000007D7B
(2) Mute Control(0x42)
Example (input channel 1 mute): 7B7D01420000017D7B
(3)Load Preset Control(0x43)
Example (recall user preset U00):7B7D01430100007D7B
EXTEND REMOTE CONTROL PROTOCOL
0
1 2
3
4
5
6
7
8
DLE STX
Device
Assress
CMD
Data1 Data2
Date3
Packet
0x7B 0x7D 1～254
0x41～0x4A
0x? ? 0x7D0x? ? 0x? ? 0x7B
STX DLE
0
1 2
3
4
5
6
7
8
DLE STX
Device
Assress
CMD
Packet
0x7B 0x7D 1～254 0x7D 0x7B
STX DLE
0x41
In:0 Out: 1
0～3
+: 0, - : 1
Channel + /-
In/Out
0
1 2
3
4
5
6
7
8
DLE
STX
Device
Assress
CMD
Packet
0x7B 0x7D 1～254 0x7D 0x7B
STX
DLE
0x42
In:0 Out: 1
0～3
No:0 Yes:1
Channel No/Yes
In/Out
Packet
0
1 2
3
4
5
6
7
8
DLE
STX
Device
Assress
CMD
0x7B 0x7D 1～254 0x7D 0x7B
STX
DLE
0x43
F:0 U:1
0～31
0
Preset
0x30
Factory/User
