7
external processors like graphic equalisers in the main left and
right signal prior to the MASTER volume control.
8. LEFT and RIGHT RCA phono outputs :
Unbalanced signal suitable for HI-FI amplifiers and recorders.
9. LEFT and RIGHT balanced XLR outputs :
Balanced signal suitable for professional amplifiers and sound
systems.
10. AC Power Input.
11. Voltage Selector (located on the side panel) :
Do not adjust this switch when the A.C. power cord / mains lead
is connected. For supplies between 220 and 240V use the 230V
position. For supplies between 110 and 120V use the 115V
position.
9 8
10
11
