1. Introduction
Thank you for buying the Studiomaster Professional Platinum Series Mixer.
To ensure maximum performance & safety, please follow this instruction manual carefully.
Please retain this manual for future reference.
For any complaint, feedback or testimonials please contact our distributor / dealer.
Retain the cartons for future use should the product require servicing / maintenance.
2. Features at a Glance
• 16 Channel Mixer (Mono XLR 16 Mic / 12 Line + 4 Mon/Ster).
• 3 Band EQ with mid-sweep on mono channel.
• Mon-Ster Input for full Flexibility.
• 2 Aux Sends / 1Stereo Aux Returns.
• 2 Aux, 1EFX, 1 Mon rotary control on each channel (Total 4 Aux sends).
• Listen (PFL) & Group / Master routable switch per channel.
• Stereo 7 Band Graphic EQ switchable to Master / Monitor.
• Globally switched +48V phantom power.
• L/R pan control on each channel.
• 12 Segment L/R LED meter for Master, PFL & Monitor Level.
• Separate master fader control for Group, Monitor & L/R output.
• 1/4’’ jack for Line out & monitor output.
• Balanced XLR & 1/4” Jack Master output.
• Stereo Tape In/Tape Out, Headphone out with rotary volume control.
Models Available :
Platinum Basic MKI : 16 Mic/12 Line + 4 Mono/Stereo.
Platinum MKIII : 16 Mic/12 Line + 4 Mono/Stereo.
Platinum 12Fx: 12 Mic/10 Line + 2 Mono/Stereo.
Platinum MK III Additional Features:
• 16 bit (32 bit internal) digital stereo EFX with user editable parameters.
• High quality 147 preset effects with 4-memory switch and on board help.
Platinum Series Summary :
Platinum Basic MKI Platinum MKIII Platinum 12Fx
Inputs 16 Mic + 12 Line + 16 Mic + 12 Line + 12 Mic + 10 Line +
4 Mono/Stereo 4 Mono/Stereo 2 Mono/Stereo
Effects processor Provision to connect Internally available Internally available
External Effect processor
Graphic Equalizer Available Available Unavailable
Effect Section:
Digital Processor Unavailable Available Available
Storing & Recalling memory Unavailable Available Available
Stand by function Unavailable Available Available
Aux Muting Unavailable Available Available
7 segment Display Unavailable Available Available
Effect Send Return Available Unavailable Unavailable
