7
LEFT & RIGHT FADER: To control Master (L/R) output levels.
17)
18)
19)
20)
21)
22)
23)
24)
25)
26)
STEREO AUX INPUT: Provides a useful extra stereo line input. Any stereo line signal can be connected, stereo drum or
keyboard sounds, CD or the return from an external stereo processor.
Un-Balanced TRS
Tip
Sleeve
Signal
Ground
MASTER (L/R) OUTPUT: This output is used to connect the master output of the mixer to the amplifier or powered
speakers. The output level is determined by the master fader (L/R). Wiring configuration is as follows :
Pin 1 = Ground
Pin 2 = Hot (+ve Phase) Pin 3 = Cold (-ve Phase)
Note:- For connector wiring information please refer page no. 14.
LINE (L/R) OUTPUT: This ¼” 3 pole jack socket is used to connect the master output of the mixer to the amplifier or
powered speakers. The output level is determined by the master fader (L/R). Wiring configuration is as follows :
Sleeve = Ground
Tip = Send (To Effects) Ring = Return (To Console)
TO MON CONTROL - Adjusts the amount of stereo Aux Input signal going to the Foldback Mic. This allows any External
effect to be heard in the Foldback Mic.
LEVEL CONTROL - Adjusts the level of the signal from the stereo Aux Input jacks.
PLAYBACK/RECORD: The Platinum series mixers have 2 stereo RCA connectors for recording or playback.
•
•
•
Record: This RCA output is provided to record master mix on to a recording media like tape machine, hard disk
recorders and computer based audio interfaces etc. The output level of this determined by the master L/R fader;
alternately the input level on the recording medium can be used for the same.
Playback IN: This RCA input is provided to connect external devices like CD player, iPod’s, MP3 players etc.
Playback Switch: To toggle between the two record mode & Playback mode.
Please Note: Do not press the layback button while recording, especially when using the same device for recording &
play back, this will send the output signal back to the input & cause oscillations.
P
+48V PHANTOM POWER SWITCH & LED: Connects 48V phantom power to all mono channels mic inputs. For use
with +48V Phantom powered mics or DI boxes. See Options page for alternative arrangements. The Switch is released to
prevent accidental operation and should be operated using a ballpoint pen or a similiar instruments. A red warnings LED
indicates that the phantom power is turned on . When phantom power is active all microphones should be plugged in
before the console is switched on. Before using +48V Phantom power always check the microphones is suitable for +48V
Operation. Unbalanced microphones must not be used in any channel where phantom power is active.
HEADPHONES
METERS: The two bargraph meters normally monitor the Left and Right output levels.
• In Split mode, the left meter follows the main PA mix and the right follows the monitor Level. (Only for MKI & MKIII)
Meter/Phones Select Switch: Switches the meters and phones to monitor either the Main PA(L-R) or the MON
(MONITOR) Mix. When any LISTEN buttons are down, their signals will be monitored.
Phones Control: Adjusts the headphone level as per requirements when soloing a certain channel from the Main
Mix or while monitoring your mix.
