25
/04.2016/G35
R134a R410A
bar 0,5 3,0
bar 1,5 6,0
bar 24,5 36,0
bar 18,0 29,0
bar 28 40
EN
Nominal conditions
Model CR... - A/AS CR... - GS CR... - GES CR... - CW
Return air temperature °C 35
Return air humidity
% r. h.
25
Condensation temperature
°C
45 –
Water inlet temperature °C – 30 30 (10)* 10
Water outlet temperature
°C
– 40 40 (16)* 15
Refrigerant R410A
R410A
(100% water)
100% water
* values for free cooling/winter operation in parentheses
The sound pressure levels are valid at a height of 1m and distance of 2m in front of the unit under free field condi-
tions and with nominal data. The values take into account the effects of all installation and design parts contained
in the standard unit.
Adjustment of the pressure switches:
LP switch:
releases at:
automatic reset at:
HP switch:
releases at:
manual reset possible at:
Safety valve:
