Stulz CRS 211 A - Creating a Vacuum

45
/04.2016/G35
1
2
3
4
5
6
7
8
9
EN
Refrigerant bottle
Vacuum pump
Vacuum
meter
Pressure
measuring
station
Filling station with prom-
mable scale
Explanation of the evacua-
tion process with reference
to the numbers overleaf
High pressure side
(to condenser)
Low pressure side
6.3.3 Creating a vacuum
