Stulz CyberWall CAH - Page 19

19 © STULZ USA – all rights reserved 11.8.22
CYBERWALL™ INSTALLATION, OPERATION AND MAINTENANCE MANUAL
Figure 8. Connecting Internal Water Lines
FAN ACCESS
PANEL REMOVED
ROLL GROOVE
COUPLING
(2 PL)
COPPER
TUBING
COPPER
TUBING
ROLL GROOVE
COUPLING
FOAM
INSULATION
FOAM
INSULATION
APPLY ADHESIVE
TO SEAMS. BUTT
END OF INSULATION
AGAINST COUPLING.
FOAM TUBING LENGTH
AS REQUIRED.
FOAM
INSULATION
FOAM
INSULATION
FOAM
INSULATION
