CYBERWALL™ INSTALLATION, OPERATION AND MAINTENANCE MANUAL
AA
H
H
GG
REMOVE ACCESS
PANEL
P-TRAP
CONDENSATE
DRAIN
SECTION A-A
BOTTOM MODULE
M8-1.25 X 25MM
HHCS SERRATED
FLANGE BOLTS
(10 PL)
60-INCH
COPPER TUBE
SEE SECTION H-H
AIRBLOCK
FLEXIBLE
COUPLING
PIPE CLAMP (207756)
(W/ NO SHIMS)
FLEXIBLE
COUPLING
DRAIN ACCESS
PANELS
GROMMET
SECTION G-G
P-TRAP
SECTION H-H
PIPE CLAMP (207756)
(W/3X SHIMS)
Figure 7. Attaching Condensate Drain
