CYBERWALL™ INSTALLATION, OPERATION AND MAINTENANCE MANUAL
WARNING
Never operate the unit with any cover, guard, screen panel, etc., removed unless the instructions
specifically state otherwise, and then do so with extreme caution to avoid personal injury.
CAUTION
If a lifting device is used to move a unit, ensure it is capable of supporting the weight of the unit.
CAUTION
Do not use cleaning solvents near open flame or excessive heat. Wear eye protection when blowing
solvent from parts. The pressure-wash should not exceed 30 psig. Solvent solutions should be disposed
of in accordance with local and state regulatory statutes.
CAUTION
After the customer furnished supply and return piping is assembled, the piping system must be
thoroughly cleaned prior to connecting it to the unit. Failure to do so will result in equipment problems.
CAUTION
After the supply and return piping is connected to the unit, the entire system must be flushed prior to
beginning operation.
CAUTION
When installing and filling the water/glycol loop, all air must be bled from the piping system.
CAUTION
Once in service, a CyberWall™ unit should not be drained and taken out of service for an extended period
of time. Formicary corrosion can occur.
CAUTION
When the air conditioner is in the cooling mode, the return air-intake and discharge (supply) must be free
of obstructions. Ensure panels are secure and latched into position.
For optimal performance and to ensure continuous operation, only use STULZ spare parts. Product Support
provides spare and replacement parts by fax, phone and email. Refer to “Product Support” on page 34 for
guidance on contacting STULZ support.
General Design
The CyberWall™ unit is housed in a steel frame cabinet and is rated for indoor use. The cabinet frame
members and exterior panels are coated with a durable powder coat finish to protect against corrosion.
The system is designed to be located adjacent to or inside the space to be conditioned. It is mounted on an
optional floor stand, which is in turn secured to the floor.
Hinged access doors are provided for access to major serviceable components. Primary operator control is
through the Graphical Terminal mounted on the controller box access door. Other electrical controls are in the
main electric box. The installation drawing provided with your unit for the cabinet layout, unit dimensions, unit
weight, location of access doors and utility interfaces.
