WDE
27 © STULZ SpA . – all rights reserved EN/36B/08.2018
Condensate water tray
Compressor
Air filter
Electric box
Damper block
Condenser fan
Condenser
Thermostatic expansion
valve
Evaporator
Evaporator fan
WDE size 2 (A0A2A4A6)
