TECHNICAL DATA
5-3
MODEL 501F
Prior To Serial # M/P1204990/P1214440 and except
between #M/P1104940 to M/P1105139
Freezer
Charge (R-12 Refrigerant) 10.0 oz.
Control (normal #5 setting)
Prior to #M66311/P679466 and from
#M/P960170 to #M/P960319 and from
#M/P996400 to #M/P996574 and starting
with #M/P1004775.
Service Part No. 3012541
- Cut-in/Cut-out 10.0° / -6.0° F
From #M66311/P679466 to
#M/P960170 and from #M/P960319 to
#M/P996400 and from #M/P996574
to #M/P1004775.
Service Part No. 3012750
- Cut-in/Cut-out -3.0°/-18.0° F
Compressor
Service Part No. 4202560
Mfg. Part No. DA9L
Service Compressor Amps 10.8
Service Compressor BTU’s 1151
Suction Pressure (PSIG)
- Cut-in/Cut-out 14 / 1
Original Defrost Timer (Cycle)
Prior to #M/P960171 and from
#M/P960319 to #M/P996400 and
from #M/P996574 to #M/P1004775.
- Interval 12 hour
Continuous
- Duration 15 minute
From #M/P960171 to #M/P960319 and
from #M/P996400 to #M/P996574
and starting with #M/P1004775.
- Interval 12 hour
(comp. run)
- Duration 15 minute
Service (6hr/21min) Part No. 3081180
Defrost Terminator
- Cut-in/Cut-out 30.0° / 55.0°F.
Defrost Heater
- Watts 640
- Amps 5.5
- Ohms 2.1
Drain Tube Heater
- Watts 15
- Amps 0.13
- Ohms 900
Drain Trough Heater
- Watts 50
- Amps 0.4
- Ohms 260
Fill Tube Heater
(Starting with #M1184540/P1200040)
- Watts 5
- Amps 0.04
- Ohms 2600
MODEL 501F
Starting with Serial # M/P1204990/P1214440
and between #M/P1104940 to M/P1105139
Freezer
Charge (R-134a Refrigerant) 11.0 oz.
Control (normal #5 setting)
Service Part No. 3012541
- Cut-in/Cut-out 10.0° / -6.0° F
Compressor
Service Part No. 4201870
Mfg. Part No. RG108
Service Compressor Amps 1.4
Service Compressor BTU’s 830
Suction Pressure (PSIG)
- Cut-in/Cut-out 13 / -1" Vac
Original Defrost Timer (Cycle)
- Interval 12 hour
(comp. run)
- Duration 15 minute
Service (6hr/21min) Part No. 3081180
Defrost Terminator
- Cut-in/Cut-out 30.0° / 55.0°F.
Defrost Heater
- Watts 640
- Amps 5.5
- Ohms 2.1
Drain Tube Heater
- Watts 15
- Amps 0.13
- Ohms 900
Drain Trough Heater
- Watts 50
- Amps 0.4
- Ohms 260
Fill Tube Heater
- Watts 5
- Amps 0.04
- Ohms 2600
