Sub-Zero 501R User Manual

TECHNICAL DATA
5-4
MODEL 511
Prior To Serial # M/P1204690
Refrigerator Freezer
Charge (R-12 Refrigerant)
Prior to #M/P964470 and
from #M/P964769 to #M/P1004775 7.0 oz. 8.0 oz.
From M/P9644470 to M/P964769 and
from #M/P1004775 to #M/P1204690 9.0 oz. 8.0 oz.
Control (normal #5 setting)
Service Part No. 4201260 3014280
- Cut-in/Cut-out 39.0°/31.0° F 14.0°/-2.0° F
Compressor
Service Part No. 4201670 4201400
Mfg. Part No. EM30SC D120
Service Compressor Amps 0.8 1.4
Service Compressor BTU’s 318 762
Suction Pressure (PSIG)
- Cut-in/Cut-out 36 / 16 15 / 1
Original Defrost Timer (Cycle)
Prior to #M/P964470 and from
#M/P964769 to #M/P1004775
Interval ---- 12 Hour
Continuous
Duration ---- 15 Minutes
From #M/P964470 to #M/P964769 and
from #M/P1004775 to #M/P1204690
Interval ---- 24 Hour
(comp. run)
Duration ---- 20 Minutes
Service (6hr/21min) Part No. ---- 3081180
Defrost Terminator
- Cut-in/Cut-out ---- 30.0°/55.0°F
Defrost Heater
- Watts ---- 640
- Amps ---- 5.5
- Ohms ---- 21
Drain Tube Heater
- Watts ---- 7
- Amps ---- 0.06
- Ohms ---- 1890
Drain Trough Heater
- Watts ---- -----
- Amps ---- -----
- Ohms ---- -----
Fill Tube Heater
- Watts ---- 5
- Amps ---- 0.04
- Ohms ---- 2600
MODEL 511
Starting with Serial # M/P1204690
Refrigerator Freezer
Charge (R-134a Refrigerant) 10.0 oz. 8.5 oz.
Control (normal #5 setting)
Service Part No. 4201260 3014280
- Cut-in/Cut-out 39.0°/31.0° F 14.0°/-2.0° F
Compressor
Service Part No. 4201880 4201870
Mfg. Part No. EMI30HER RG108
Service Compressor Amps 0.9 1.4
Service Compressor BTU’s 280 830
Suction Pressure (PSIG)
- Cut-in/Cut-out 38 / 16 14 / -2" Vac
Original Defrost Timer (Cycle)
Interval ---- 24 Hour
(comp. run)
Duration ---- 20 Minutes
Service (6hr/21min) Part No. ---- 3081180
Defrost Terminator
- Cut-in/Cut-out ---- 30.0°/55.0°F
Defrost Heater
- Watts ---- 640
- Amps ---- 5.5
- Ohms ---- 21
Drain Tube Heater
- Watts ---- 7
- Amps ---- 0.06
- Ohms ---- 1890
Drain Trough Heater
- Watts ---- -----
- Amps ---- -----
- Ohms ---- -----
Fill Tube Heater
- Watts ---- 5
- Amps ---- 0.04
- Ohms ---- 2600
