TECHNICAL DATA
5-5
MODEL 532
Prior To Serial # M1206090/P1213890 except between
#M/P185040 to #M/P1185139, and except between
#M/P1203740 to #M/P1203839
Refrigerator Freezer
Charge (R-12 Refrigerant)
Prior to #M681568 11.0 oz. 12.0 oz.
From #M681568/P612141 to
#M/P964770 and from
#M/P965069 to #M/P1004775 7.0 oz. 8.0 oz.
From #M/P964770 to #M/P965069 and
from #M/P1004775 to #M/P1185040
and from #M/P1185139 to
#M/P1203740 and from #M/P1203839
to #M1206090/P1213890 10.0 oz. 10.5 oz.
Control (normal #5 setting)
Prior to #M681568/P612141
Service Part No. 4201260 3012670
- Cut-in/Cut-out 39.0°/31.0° F 1.5°/-5.0° F
Starting with #M681568/P612141
Service Part No. 4201260 3012742
- Cut-in/Cut-out 39.0°/31.0° F -1.5°/-8.5° F
Compressor
Service Part No. 4201670 4201400
Mfg. Part No. EM30SC D120
Service Compressor Amps 0.8 1.4
Service Compressor BTU’s 318 762
Suction Pressure (PSIG)
Prior to #M681568/P612141
- Cut-in/Cut-out 36 / 16 10 / 1
Starting with #M681568/P612141
- Cut-in/Cut-out 36 / 16 13 / 4
Original Defrost Timer (Cycle)
Prior to #M681568/P612141
Interval ---- 12 Hour
Continuous
Duration ---- 15 Minutes
From#M681568/P612141 to
#M/P964770 and from
#M/P965069 to #M/P1004775
Interval ---- 24 Hour
(comp. run)
Duration ---- 15 Minutes
From#M/P964770 to M/P965069
and from #M/P1004775 to
#M1206090/P1213890
Interval ---- 24 Hour
(comp. run)
Duration ---- 20 Minutes
Service (6hr/21min) Part No. ---- 3081180
Defrost Terminator
- Cut-in/Cut-out ---- 30.0°/55.0°F
Defrost Heater
- Watts ---- 640
- Amps ---- 5.5
- Ohms ---- 21
Drain Tube Heater
- Watts ---- 7
- Amps ---- 0.06
- Ohms ---- 1890
Drain Trough Heater
- Watts ---- -----
- Amps ---- -----
- Ohms ---- -----
Fill Tube Heater
- Watts ---- 5
- Amps ---- 0.04
- Ohms ---- 2600
MODEL 532
Starting with Serial # M1206090/P1213890 and between
#M/P185040 to #M/P1185139, and between
#M/P1203740 to #M/P1203839
Refrigerator Freezer
Charge (R-134a Refrigerant) 10.0 oz. 9.0 oz.
Control (normal #5 setting)
Service Part No. 4201260 3012742
- Cut-in/Cut-out 39.0°/31.0° F -1.5°/-8.5° F
Compressor
Service Part No. 4201880 4202250
Mfg. Part No. EMI30HER DA73
Service Compressor Amps 0.9 1.4
Service Compressor BTU’s 280 860
Suction Pressure (PSIG)
- Cut-in/Cut-out 38 / 11 9 / -1" Vac
Original Defrost Timer (Cycle)
Interval ---- 24 Hour
(comp. run)
Duration ---- 20 Minutes
Service (6hr/21min) Part No. ---- 3081180
Defrost Terminator
- Cut-in/Cut-out ---- 30.0°/55.0°F
Defrost Heater
- Watts ---- 640
- Amps ---- 5.5
- Ohms ---- 21
Drain Tube Heater
- Watts ---- 7
- Amps ---- 0.06
- Ohms ---- 1890
Drain Trough Heater
- Watts ---- -----
- Amps ---- -----
- Ohms ---- -----
Fill Tube Heater
- Watts ---- 5
- Amps ---- 0.04
- Ohms ---- 2600
