TECHNICAL DATA
5-6
MODEL 542
Refrigerator Freezer
Charge (R-134a Refrigerant) 9.0 oz. 7.5 oz.
Control (normal #5 setting)
Service Part No. 4201260 4202742
- Cut-in/Cut-out 39.0°/31.0° F -1.5°/-8.5° F
Compressor
Service Part No. 4201880 4202250
Mfg. Part No. EMI30HER DA73
Service Compressor Amps 0.9 1.4
Service Compressor BTU’s 280 860
Suction Pressure (PSIG)
- Cut-in/Cut-out 38 / 11 9 / -1" Vac
Original Defrost Timer (Cycle)
Interval ---- 24 Hour
(comp. run)
Duration ---- 20 Minutes
Service (6hr/21min) Part No. ---- 3081180
Defrost Terminator
- Cut-in/Cut-out ---- 30.0°/55.0°F
Defrost Heater
- Watts ---- 516
- Amps ---- 4.5
- Ohms ---- 26
Drain Tube Heater
- Watts ---- 7
- Amps ---- 0.06
- Ohms ---- 1890
Drain Trough Heater
- Watts ---- -----
- Amps ---- -----
- Ohms ---- -----
Fill Tube Heater
- Watts ---- 5
- Amps ---- 0.04
- Ohms ---- 2600
