A
A
A) ALL REVEALS ARE
1
/8" (3) *DIMENSIONS MAY VARY
SIDE VIEW
24"
(610)
PANEL WIDTH
26
3
/4"* (679)
13
9
/16"
(345)
16
11
/16"*
(424)
4"*
(102)
34
1
/2"
(876)
*
27"
(686)
FINISHED OPENING
TOE KICK
FRAMELESS CABINETRY APPLICATIONS
The illustration below shows a hypothetical installation of
an Integrated drawer unit within frameless cabinetry.
Review the illustration, giving particular attention to the
overall panel specifications.
IMPORTANT NOTE: Dimensions are based on a
1
/8" (3)
r
eveal. A reveal of up to
1
/4"
(6) is possible, but panel
dimensions need to be adjusted accordingly.
FRAMELESS CABINETRY
Planning Information
Integrated Model 700BR
9
Installation of an Integr
ated dr
awer unit
within frameless cabinetry.
*Dimensions may vary.
Dimensions in parentheses are in
millimeters unless otherwise specified.
