WINE STORAGE
Opening Dimensions
MODEL WS-30 | BW-30 FLUSH INSET INSTALLATION
FLUSH INSET WIDTH
W
WS-30 32" (813)
BW-30 32" (813)
Dimensions assume a
3
/4" (19) panel thickness.
If an 83"
(2108) grille height is specied, the ush inset height
must be decreased by
7
/8" (22). If an 88" (2235) grille height
is specied, the ush inset height must be increased by 4"
(102)
.
If two units are installed side by side, refer to page 67 for
dual ush inset installations.
84"
(2134)
FLUSH
INSET
HEIGHT
1
/4"
(6)
26
3
/16"
(665)
FLUSH
INSET
DEPTH
2
3
/16"
(56)
*3
" (76) typical depth. Shaded areas will be visible and should be finished to match cabinetry.
NOTE: Shaded line represents profile of unit with
3
/4" (19) panel.
FRONT VIEW
SIDE
VIEW
TOP VIEW
FINISHED
CLEATS*
1
1
/4"
(32)
W
FLUSH INSET WIDTH
4" (102)
1
1
/4"
(32)
2
3
/16"
(56)
3"
(76)*
TYPICAL
