Sub-Zero BI-48S - Backer Panel 29

84 | Sub-Zero Customer Care 800.222.7820
WINE STORAGE
23
7
/8"
(606)
TO REAR OF UNIT
OVERALL WIDTH OF UNIT
1
1
/
4
"
(32)
1
1
/
2
"
(38)
1
3
/
4
"
(44)
0"
(0)
1"
(25)
2"
(51)
2
1
/
4
"
(57)
2
1
/
2
"
(63)
2
3
/
4
"
(70)
3"
(76)
3
1
/
4
"
(83)
3
1
/
2
"
(89)
1
/
4
"
(6)
1
/
2
"
(13)
3
/
4
"
(19)
3
/4"
(19) THICK
OVERLAY PANEL
(TYPICAL)
1
/
4
"
(6) BACKER
PANEL
1"
(25) THICK
PANEL
1" (25)0"
SCALE
90° door opening (top view).
UNDERCOUNTER WINE INTEGRATED PRO 48 BUILT-IN
Overlay Application—WS-30 | BW-30
FULL-SCALE TEMPLATE
