Sub-Zero BI-48S - Page 85

subzero.com/specs | 85
WINE STORAGE
1
1
/
4
" (32)
ASSUMES
3
/4" (19)
FLUSH INSET
PANEL
THICKNESS
2
3
/
16
"
(56)
24"
(610)
TO BACK WALL
3
/
4
" (19) THICK
FLUSH INSET PANEL
(TYPICAL)
1
/4" (6) BACKER
PANEL
1" (25) THICK
PANEL
1" (25)0"
SCALE
110° door opening (top view).
BUILT-IN PRO 48 INTEGRATED WINE UNDERCOUNTER
Flush Inset Application—WS-30 | BW-30
FULL-SCALE TEMPLATE
For panels thicker than
3
/4" (19), a 90° door stop may be
required to prevent interference with adjacent cabinets.
