SUB-ZERO WINE STORAGE
Opening Dimensions
WINE STORAGE
OPENING DIMENSIONS
COLUMN A B
ICBIW-18 457 mm 2134 mm
ICBIW-24 610 mm 2134 mm
ICBIW-30 762 mm 2134 mm
TALL A B
ICBIW-30R 762 mm 2134 mm
The depth of each wine storage model is 610 mm. Allow for
panel thickness when planning the nished opening depth.
Approximately 89 mm of the opening depth may be visible
when the door/drawers are open and should be nished to
match cabinetry. Refer to the illustration below.
DUAL INSTALLATION
The wine storage unit can be installed next to an integrated
unit or another wine storage unit in a dual installation. When
installing two units side by side, the opening width is the
width of the two units added together. A dual installation
kit will be required for this installation. If a dual installation
kit is not specied, a minimum 51 mm ller strip is required
between units.
Dual installation kits are available through an authorized
Sub-Zero dealer. For questions regarding the installation,
contact your authorized Sub-Zero dealer.
DETAIL
635 mm
OPENING
DEPTH
A
OPENING WIDTH
635 mm
OPENING DEPTH
B
OPENING
HEIGHT
TOP VIEW
FRONT VIEWSIDE VIEW
89 mm
(TYPICAL)
19 mm
(TYPICAL)
SHADED AREA
SHOULD BE
FINISHED
TO MATCH
CABINETRY
