Sub-Zero IT30RRH Installation Guide

10 | Sub-Zero Customer Care 800.222.7820
Custom Panels
For integrated models, custom door panels and handle
hardware must be installed. Stainless steel panels are
available through an authorized Sub-Zero dealer. For local
dealer information, visit the nd a showroom section of our
website, subzero.com.
The thickness of the custom panel can vary. A minimum
5
/8" (16) thick panel is required, but the thickness can be
increased provided it does not exceed the maximum panel
weight indicated in the chart below. The depth of each
integrated model is 24"
(610). Allow for panel thickness when
planning the nished opening depth.
PANEL REQUIREMENTS
COLUMN MAX WEIGHT
18" Models 45 lb (20 kg)
24" Models 60 lb (27 kg)
30" / 36" Models 75 lb (34 kg)
TALL (DOOR) MAX WEIGHT
30" Models 50 lb (22 kg)
36" Models 60 lb (27 kg)
DRAWER MAX WEIGHT
All Drawer Panels 15 lb (7 kg)
PANEL THICKNESS MINIMUM
All Panels
5
/8" (16)
Reveals between panels can vary,
1
/8" (3) reveals are typical.
CAUTION
When installing a panel thicker than 1" (25), the 90° stop
may be required to prevent damage to the unit and
adjacent cabinetry.
CAUTION
As reveals between cabinetry and the unit decrease,
severe nger pinching can occur while door is closing.
Finish all sides of custom panels. They will be visible when
the door is open.
D-style handles are recommended. Stainless steel tubular
and pro handles are avail able through an authorized
Sub-Zero dealer. For local dealer information, visit the nd
a showroom section of our website, subzero.com. Door
handles must be located near the edge of the panel oppo-
site the hinge and should be centered top to bottom. Drawer
handles must be located near the top edge of each panel.
DUAL INSTALLATION
When installing two units side by side in a dual installa-
tion, the opening width is the width of the two units added
together. A dual installation kit will be required for this
installation.
Dual installation kits are available through an authorized
Sub-Zero dealer. For local dealer information, visit the nd a
showroom section of our website, subzero.com. For ques-
tions regarding the installation, call Sub-Zero customer care
at 800-222-7820.
PANEL INSTALLATION

Sub-Zero IT30RRH Specifications

General

Type	built-in
Style	no freezer
Color	custom, custom panel ready
Number of Doors	3
Total Capacity	16.5 cubic feet
Refrigerator Capacity	16.5 cubic feet
Defrost System	automatic
Number of Refrigerator Shelves	3
Temperature Control	electronic
Interior Light	led
Dispenser	none
Ice Maker	no
Water Filter	no
Air Filter	yes
Door Alarm	yes
Smart Home	yes
Wi-Fi	wi-fi
Annual Energy Consumption	324 kilowatt hours
Voltage	115 volts
Current	15 amperes

Weight and Dimensions

Depth	24 inches
Height	84 inches
Width	30 inches
Net Weight	400 pounds
