Sub-Zero SZ-7524-P

SUGGESTED WIRING DIAGRAM
COIL
ROOM
PHASE
NEUTRAL
Caution : Wiring for 230Vac Loads Only.
Fan
(8(3)A max)
To
SZ-N75
To
SZ-N75
Heater
(8(3)A max)
NOCNC NO
To
SZ-B75
(10Vdc,10mA max)
BUZZER
10
12VDC
1 2
3
4
5
6
7
8 9
11 12
NO
COMP.
FAN DEFROST
SZ-7524-P (12VDC)
+
-
COIL
ROOM
PHASE
NEUTRAL
Caution : Wiring for 230Vac Loads Only.
Fan
(8(3)A max)
To
SZ-N75
To
SZ-N75
Heater
(8(3)A max)
NOCNC NO
To
SZ-B75
(10Vdc,10mA max)
BUZZER
10
230V
1 2
3
4
5
6
7
8 9
11 12
NO
COMP.
FAN DEFROST
SZ-7524-P (230V)
+
-
11
12VDC
12
SZ-7524-P
COIL
71mm
29mm
Panel cutout
3
1
4
2
34.5mm
71mm
19mm
10mm
MAX
