CAUTION
WIRING : The probe and its corresponding wires should never be installed in a conduit
next to control or power supply lines. The electrical wiring should be done as shown in
the diagram. The power supply circuit should be connected to a protection switch. The
terminals admit wires of upto 2.5sq mm.
WARNING : Improper wiring may cause irreparable damage and personal injury.
Kindly ensure that wiring is done by qualified personnel only.
Maintenance : Cleaning: Clean the surface of the controller with a soft moist cloth. Do
not use abrasive detergents, petrol, alcohol or solvents.
Installation : Fixing and dimensions of panel models:
To fix the unit, slide the fastener 1 through the guides 2 as per the position shown in the
figure. Move the fastener in the direction of the arrow, pressing tab 3 it permits to move
the fastener in the opposite direction of the arrow. Once the controller has been
connected, they should be covered with the lid 4. Silicon sealant should be applied along
the perimeter of the panel cut out or a rubber ‘O’ ring supplied before the unit is fitted to
increase protection against water seepage.
Controller :Controller should be installed in a place protected by vibration, water and
corrosive gasses and where ambient temperature does not exceed the values specified in
the technical data.
Probe :To give a correct reading, the probe must be installed in a place protected from
thermal influences, which may affect the temperature to be controlled.
Notice: The information in this document is subject to change in order to improve reliability ,
design or function without prior notice and does not represent a commitment on the part of the
company. In no event will the company be liable for direct, indirect, special, incidental or
consequential damage arising out of the use or inability to use the product or documentation,
even if advised of the possibility of such damages. No part of this manual may be reproduced
or transmitted in any form or by any means without the prior written permission of the
company.
Disclaimer : This manual & its contents remain the sole property of A.S. CONTROLS Pvt. Ltd,
India and shall not be reproduced or distributed without authorisation. Although great care has
been taken in the prepartion of this document, the company or its vendors in no event will be
liable for direct, indirect, special, incidental or consequential damage arising out of the use or
inability to use the product or documentation, even if advised of the possibility of such
damages. No part of this manual may be reproduced or transmitted in any form or by any
means without the prior written permission of the company. A.S. CONTROLS Pvt. Ltd,
reserves the right to make and changes or improvements without prior notice.
Warranty : This product is warranted against defects in materials and workmanship for a
period of one year from the date of purchase. During the warranty period, product
determined by us to be defective in form or function will be repaired or, at our option, replaced
at no charge. This warranty does not apply if the product has been damaged by accident,
abuse, and misuse or as a result of service or
modification other than by the company. This warranty is in lieu of any other warranty
expressed or implied. In no event shall the company be held liable for incidental or
consequential damages, such as lost revenue or lost business opportunity arising from the
purchase of this product.
