11-54
Maintenance and service
A) Stopper
Be sure to position the claws at the end of the metal
support between the stoppers on the rubber as shown.
If the rubber is not retained properly, the wiper blade
may scratch the windshield.
6. Install the wiper blade assembly to the wiper arm.
Make sure that it locks in place.
7. Lower the wiper arm.
Rear window wiper blade
1. Raise the wiper arm off the rear window.
2. Turn the wiper blade assembly counterclockwise.
A
HSB062BC
USB581BA
To Next Page
