Climate control/Ventilator control
Ventilator control
& Center ventilators
1) Open
2) Close
Move the tab to adjust the flow direction.
To open the ventilator, turn the center grille
open/close wheel upward to the “
”
position.
To close it, turn the wheel downward to the
“
” position.
& Side ventilators
1) Open
2) Close
Move the tab to adjust the flow direction.
To open the ventilator, turn the side grille
open/close wheel upward to the “
”
position.
To close it, turn the wheel downward to the
“
” position.
& Rear ventilators (if equipped)
1) Open
2) Close
Move the tab to adjust the flow direction.
To open the ventilator, turn the rear grille
open/close wheel upward to the “
”
position.
To close it, turn the wheel downward to the
“
” position.
4-2
