Maintenance and service/Air cleaner element
2. Open the air cleaner case.
3. Remove the air cleaner element.
CAUTION
If the inside of the air cleaner case is
extremely soiled (for example, by
sand), contact a SUBARU dealer
and have the air cleaner case
cleaned.
4. If you find large foreign objects such
as leaves inside the air cleaner case,
remove the foreign objects.
5. Install a new air cleaner element in the
way the longitudinal side and the trans-
verse side face as shown in the illustra-
tion.
6. To install the air cleaner case (rear),
insert the three projections on the air
cleaner case (rear) into the slits on the
air cleaner case (front).
7. Install in the reverse order of removal.
11-16
