Subaru EA190V Service Manual

31
FLYWHEEL (CAST IRON)
HOLE
HOLE
IMPELLER
LUG
LUG
STARTER CUP
Assembly:
a) Clean the tapered part of dirt, oil grease and other foreign material before installation.
Be sure that there is no washer and other foreign material on the magnetic part.
b) Set the key in the key groove.
c) Install the flywheel over the crankshaft.
NOTICE: The flywheel may push the key out of its slot, check after assembling.
・Flywheel nut torque value： 64±4N.m（ aluminum flywheel） ／ （78±4N.m iron flywheel）
Flywheel (cast iron)
・Attach by aligning the four small holes in the flywheel.
・Attach by aligning the lug on the rear side of the starter cup with the small hole at the center.
（ ）
Flywheel aluminum
FLYWHEEL (ALUMINUM)

Subaru EA190V Specifications

General

Compression Ratio	8.5:1
Lubrication System	Splash
Ignition System	Transistorized Magneto Ignition
Starting System	Recoil Starter
Oil Capacity	0.6 liters
Fuel Type	Unleaded gasoline
Engine Oil Type	SAE 10W-30
Engine Type	4-Stroke, Air Cooled, OHV
Fuel Tank Capacity	3.6 L
