- 54 -
PINION STOPPER SET
PINION A
Y
FRONT METAL
CASE METAL
FRONT COVER
ARMATURE AY
YOKE AY
THROUGH BOLT (2 pcs.)
BRUSH HOLDER
BRUSH
SPRING (BRUSH)
REAR COVER
MAGNETIC SWITCH
PINION AY
FRONT COVER
BATTERY
CABLE
ARMATURE AY
YOKE AY
O - RING
O - RING
THROUGH BOLT (2 pcs
.)
WASHER
SPRING (BRUSH)
REAR COVER
BRUSH HOLDER
BRUSH
MAGNETIC SWITCH
PINION
STOPPER SET
Fig. 9-3
9-3 COMPONENT PARTS
(Models EX17 and EX21)
(Model EX27)
