Subaru EX40 - Step 22: Main bearing cover

- 22 -
Fig.5-18
Step Parts to remove Remarks and procedures Fasteners
22
Main bearing cover Remove the flange bolts of main bearing cover from
the crankcase.
Remove the main bearing cover while tapping gently
around the cover using a plastic hammer or similar
tool. (See Fig. 5-18)
Be careful not to damage the oil gauge or oil seal or
not to lose the pipe knocks.
12 mm box spanner
M8 x 38mm : 8 pcs.
Fig.5-17
MAIN BEARING COVER
M8 x 38 BOLT : 8 pcs.
PIPE KNOCK
STEP 22
