Controls
Manual HVAC System (if equipped)
1. Temperature Control Dial
Rotate the temperature control dial from blue for cool, to red for warm.
2. Air Conditioning Button
Pressthe“A/C”buttontoactivatetheairconditioning.Pressitagaintoturnoffthe
air conditioning.
1
5
3
4
2
6
1. Air Flow Control Dial
On the automatic setting, the system determines the air ow location to achieve
the desired temperature or you can manually choose the direction of air ow. Rotate the dial
for the desired air ow position.
Defrost/Defog
To clear the windshield and front door windows of fog or frost, rotate the air ow control
dial to the defrost position, set the temperature control to the red position, and set the fan
speed control to the fastest speed.
Automatic Climate Control System (if equipped)
