IMPREZA(NA) A1830BE-A (ENGLISH)
11
Maintenance and service
11-49
– CONTINUED –
HS0193
5. Align the claws of the metal support with the
grooves in the rubber and slide the blade rubber as-
sembly into the metal support until it locks.
HS0194
1) Stopper
Be sure to position the claws at the end of the metal
support between the stoppers on the rubber as
shown. If the rubber is not retained properly, the
wiper blade may scratch the windshield.
6. Install the wiper blade assembly to the wiper
arm. Make sure that it locks in place.
7. Lower the wiper arm.
To Next Page
