Subaru IMPREZA 2002 - Rear Combination Lights

IMPREZA(NA) A1830BE-A (ENGLISH)
11
Maintenance and service
11-63
– CONTINUED –
J Rear combination lights
B Sedan
HGB011BA
1. Remove the clip from the rear trunk trim with a
regular screwdriver.
HGB012BB
1) Backup light
2) Rear turn
signal light
3) Brake light
4) Tail light
5) Brake/tail light
2. Open the rear portion of the side trunk trim panel.
3. Remove the bulb holder from the rear combina-
tion light assembly by turning it counterclockwise.
4. Remove the bulb from the socket by pushing it
and turning counterclockwise. Install a new bulb.
5. Set the bulb holder into the rear combination light
assembly and turn it clockwise until it locks.
6. Secure the rear trunk trim panel with the clips.
