Specifications
DESCRIPTION:
4-WAY Bass reflex loudspeaker. Quad-Wireable Terminals
FREQUENCY RESPONSE:
29Hz to 30kHz (+-2.5 dB)
AMPLIFIER POWER:
25W to 200W
DRIVE UNIT DETAILS:
BASS DRIVERS
2 x 165mm Shielded Woofers. Critically damped doped paper cone.
MID-BASS DRIVER
1 x 165mm Shielded Woofers. Critically damped doped paper cone.
MID-RANGE DRIVERS
1 x 130mm Shielded midrange. Critically damped doped paper cone.
Midrange Chamber volume: 1.8 litres
RIBBON TWEETER
1 x110mm Aluminium Ribbon Tweeter. Diaphragm (528 square mm)
CABINET STYLE:
Vented Enclosure. 18mm MDF (32mm MDF baffle)
Timber Veneer. 360 Degree Interlock bracing
CROSSOVER:
18-24dB/octave 4-Way crossover
DIMENSIONS (MM):
1065(H)x 230(W)x 395(D) (Excluding 32mm Plinth)
NET WEIGHT:
35 Kg
