Suburban DYNALINE DL3-0912 User Manual

9 Suburban DynaLine Owner's Manual 10/2017 Rev.1
SLOPE DOWN TO THE OUTSIDE
1"
4
SURFACE OF FINISHED
FLOOR OR TOP OF CARPET
MIN. (PROJECTION BEYOND EXTERIOR WALL)
1"
4
3 (MIN.)
1"
2
Y"
X"
MOUNTING HOLES AND SCREWS
(BY INSTALLER.)
DO NOT PUT HOLES THROUGH
WALL SLEEVE BOTTOM!
REAR GRILLE
CAULK AROUND WALL SLEEVE
SURFACE OF FINISHED EXTERIOR WALL
Y" = 14
SURFACE OF FINISHED INTERIOR WALL
CABINET FRONT
X" REPRESENTS EITHER THE
DIMENSION REQUIRED TO FLUSH
SLEEVE TO FINISHED TRIM OR
M
OLDING, OR THE DISTANCE
SLEEVE PROJECTS INTO ROOM
BEYOND FINISHED INTERIOR
WALL.
NOTE: X" CAN BE 0"
IF SLEEVE IS FLUSH
WITH FINISHED
INTERIOR WALL.
4
- ( X" + )
4
3 1
WALL INSTALLATION
FRONT GAS HOOKUP
Figure 6
CAULK (MUST BE WATER TIGHT).
DRAIN TUBE ASSEMBLY INSTALLED
UNDERNEATH WALL SLEEVE
NOTE: FOR THIS TYPE INSTALLATION,
WALL SLEEVE MUST EXTEND BEYOND
WALL A MINIMUM OF 1 1/8".
LOCATE DRAIN IN
BOTTOM OF WALL
SLEEVE. MUST BE
TO THE EXTERIOR
SIDE OF BUILDING.
AT DESIRED LOCATION
MARK AND DRILL ONE
9/16" DIA. HOLE AND
TWO 1/8" DIA. HOLES
AS ILLUSTRATED.
CAULK (MUST BE WATER TIGHT).
PRIMARY DRAIN HOLES FOR
CONDENSATE DRAINAGE TO
BUILDING EXTERIOR WHEN
USING ACCESS
ORY DRAIN KITS.
NOT
DRAIN TUBE ASSEMBLY INSTALLED
ON REAR FLANGE OF WALL SLEEVE
Figure 7
SIDE VIEW
1"
4
SLOPE DOWN TO
THE OUTSIDE
LEVELING LEGS
CABINET FRONT
WALL SLEEVE
SURFACE OF FINISHED FLOOR
OR TOP OF CARPET
5" MAX./3 1/2" MIN.
(1) INSTALL UNIT IN WALL AS DESCRIBED IN INSTALLATION MANUAL.
(2) POSITION LEVELING LEG--ONE ON EACH SIDE OF WALL SLEEVE
AND LOCATE FOUR (4) MOUNTING HOLES.
(3) DRILL FOUR 1/8" DIA. HOLES AND MOUNT LEGS USING #10 X 1/2" SCREWS PROVIDED.
(4) LEVEL UNIT BY ADJUSTING SCREW IN LEG.
FRONT VIEW
LEVELING LEGS INSTALLATION
Figure 8
