OPTIONAL ACCESSORIES
ALUMINUM GRILLE
STOCK NO. 1625
INTRODUCTION
The grille was specially designed for the DL3 Dynaline. Do not attempt to bend
or alter the design of the grille or the venting system of the Dynaline unit.
The grille will also work, as designed, for those models with rear gas hook-up.
IMPORTANT: Installation of the rear grille must be made prior to installing
the chassis as it secures from inside the wall sleeve.
ARCHITECTURAL STYLE GRILLES
NATURAL FINISH ALUMINUM GRILLE
STOCK NO. 1420
DARK BRONZE FINISH GRILLE
STOCK NO. 1418
INTRODUCTION
These architectural grilles are designed to be used as an optional/alternate for
the standard aluminum grille #1625. They are to be installed so that the angle
of the grille is in the downward position. Remember, these are special grilles.
Do not attempt to bend or alter the design of the grille, the venting system or the
Dynaline unit.
These grilles will also work, as designed, for those models with rear gas hook-
up. IMPORTANT: Installation of the rear grille must be made prior to
installing the chassis as it secures from inside the wall sleeve.
SCREW
(5) REQUIRED
WALL SLEEVE
GRILLE
A
Figure 19
SCREW
(5) REQUIRED
WALL SLEEVE
REAR GRILLE
A
Figure 18
