SPECIFICATIONS
SZ-AI1
Inputs: .................. 2
Input 1: .................. XLR/TRS Combination Input
Input 2: .................. 6.35mm TRS Jack Input
Frequency Response: ...... 20Hz – 20kHz
Impedance: .............. 10kOhm line input, 3.3kOhm
microphone input, 500kOhm HI-Z
input
Max Input Level: .......... +20dBu line input, +4dBu
microphone input, +12dBu HI-Z input
Phantom Power: .......... +48v Switchable (channel 1 only)
Output: .................. Type 2 x TRS
Max Out Level: ............ +4dBu
Bit Depth: ................ Max 24-bit / 96kHz
ADC Dynamic Range: ...... 102dBA@48kHz
DAC Dynamic Range: ...... 108dBA@48kHz
Power Requirements: ...... USB Type C (bus powered via computer)
System Requirements: ..... PC – Windows/Vista/7/8/8.1 or 10 (32
or 64 bit), Mac – OSX 10.7 or higher
Dimensions
(H x W x D mm): .......... 35 x 135 x 87 mm
Weight: .................. 0.25kg
SZ-MH1
Driver Diameter: .......... 50mm
Impedance: .............. 32Ω
Sensitivity: ............... 95dB +/- 3dB
Frequency Response: ...... 15Hz – 25kHz
Max Power: .............. 1200mW
SZC-1
Element: ................. Back Eletret Condenser
Polar Pattern: ............. Uni-directional
Frequency Response: ...... 30Hz – 18kHz
Sensitivity: ............... –38dB±2dB
(0dB=1V/Pa at 1kHz)
Output Impedance: ....... 150Ω +/- 30%
(at 1kHz)
Max SPL: ................. 134dB
(at 1kHz ≤1% T.H.D)
Equivalent Noise Level: .... 19dB A
Signal to noise ratio: ....... 75dB
Phantom power required: .. +48v
