MD24 and MD30
Installation Information
2-4
#824820 - Revision A - November, 2013
Figure 2-5. 30” Microwave Drawer Cabinet Dimensions
STANDARD INSTALLATION
FLUSH INSET INSTALLATION
E
W
FLUSH INSET WIDTH
FRONT VIEW
SIDE
VIEW
FINISHED
CLEATS
23
1
/ 4 "
(591 )
FLUSH INSET
DEPTH
1
1
/ 4 " (32)
NOTE: Dashed line represents prole of unit.
15
15
/ 16 " (405)
FLUSH INSET
HEIGHT
7
/ 16 " (11 )
3
/
4
"
(19)
ANTI-TIP BLOCK
A
TOP VIEW
E
FRONT ViEW
SIDE
VIEW
22" (559)
OPENING
DEPTH
NOTE: All Microwave Drawer ovens require the same opening dimensions.
.
Dashed line represents prole of unit
.
14
3
/ 4 " (375)
OPENING
HEIGHT
ANTI-TIP BLOCK
W
OPENING WIDTH
TOP VIEW
BASE SUPPORT
30
1
/ 8 " (765)
22
1
/
8
"
(562)
4” (102)
21
7
/ 8 " (556)
BEHIND FRAME
15
1
/ 8 "
(384)
29
7
/ 8 " (759)
21 / 8 " (549)
POWER CORD
CHANNEL
1
1
/ 4 "
(32)
4
5
/ 8 "
(118)
1
3
/ 4 "
(45)
14
5
/ 8 "
(372)
16
1
/ 2 "
(419)
OPEN DRAWER
Figure 2-4. 30” Microwave Drawer Dimensions
MD24 Specifications
Weight: 91 pounds.
Dimensions: 23-5/8” W x 15-1/8” H x 21-7/8” D.
Interior: 17-5/8” W x 7-1/8” H x 16-9/16” D.
Capacity: 1.2 cubic feet
MD30 Specifications
Weight: 96 pounds.
Dimensions: 29-7/8” W x 15-1/8” H x 21-7/8” D.
Interior: 17-5/8” W x 7-1/8” H x 16-9/16” D.
Capacity: 1.2 cubic feet
