®SULLAIR®
INDUSTRIAL AIR COMPRESSOR
1100E, 1500E, 1800E,
1100EV, 1500EV, 1800EV
11, 15 & 18KW/15, 20 & 25HP
Air-Cooled Standard & 24 KT
02250155_844_Cvr
PART NUMBER:
02250155–844
KEEP FOR
FUTURE
REFERENCE
©
SULLAIR CORPORATION
The information in this document is
correct at the time of printing for utility
compressor serial number
20060601XXXX
and all subsequent serial numbers.
OPERATOR’S MANUAL AND PARTS LIST

Table of Contents

Other manuals for Sullair 1809e

Preview: User Manual
User Manual60 pages

Questions and Answers

  • J
    Jimmy AllenAug 9, 2025
    Why is my Sullair 1809e not building full discharge pressure?
    • J
      Jennifer BowmanAug 9, 2025
      If your Sullair Air Compressor isn't building full discharge pressure, consider these potential causes: The air demand might be too great, so check service lines for leaks or open valves. The air filter might be dirty, so inspect the filter indicator and replace the element if needed. A plugged inlet valve bleed orifice could also be the problem, so ensure the control line bleed orifice is not blocked. Additionally, the pressure regulator might be out of adjustment or defective, so adjust it or replace the diaphragm if necessary. Finally, a defective unload solenoid valve could be the issue, so check that it closes when energized, and replace it if defective.
  • T
    tuckerlorraineAug 18, 2025
    Why won't my Sullair 1809e Air Compressor start?
    • T
      Travis SmithAug 18, 2025
      If your Sullair Air Compressor won't start, several factors could be the cause. First, check that the main disconnect switch is closed. Another possible cause is a blown line fuse, which would need to be replaced. Also, the motor starter overload might have tripped; try resetting it, and if the issue continues, inspect the motor starter contacts. Finally, low incoming line voltage could be the culprit, so check the voltage and consult your power company if it's too low.
  • A
    alexandraalvaradoNov 28, 2025
    What to do if my Sullair 1809e Air Compressor shuts down with air demand present?
    • J
      Jacob SmithDec 1, 2025
      If your Sullair Air Compressor shuts down while there's still air demand, there are several potential reasons. It could be due to a loss of control voltage; try resetting it, and if the problem continues, ensure the line pressure doesn't exceed the compressor's maximum operating pressure. Low incoming voltage can also cause this issue, so consult your power company. Other possibilities include the separator needing maintenance (check the indicator under full load), a high pressure setting in the WS controller (reset it), a defective unload solenoid valve (repair if defective), or a defective blowdown valve (repair if defective). Restricted cooling air flow (clean the cooler and check ventilation), high ambient temperature (improve ventilation), low fluid level (add fluid), or a malfunction...

Summary

Safety

General Safety Precautions

General safety guidelines for compressor operation and maintenance, emphasizing user responsibility.

Personal Protective Equipment (PPE)

Requirements for PPE like eye protection, hearing protection, and protective clothing during operation.

Pressure Release Procedures

Instructions on safely releasing pressure, including flow-limiting valve requirements.

Fire and Explosion Hazards

Guidelines to prevent fire and explosion, including spill cleanup and ignition source control.

Moving Parts Safety

Warnings about keeping clear of moving parts and ensuring guards are in place.

Hot Surfaces and Sharp Edges

Precautions regarding contact with hot surfaces, sharp edges, and corners on the compressor.

Toxic and Irritating Substances

Safety information on handling and exposure to lubricants, coolants, and air quality.

Electrical Shock Hazards

Safety measures to prevent electrical shock, including grounding and proper wiring.

Lifting and Handling Safety

Safe procedures for lifting, rigging, and transporting the compressor unit.

Entrapment Hazards

Precautions to prevent entrapment within the compressor enclosure during servicing.

Description

Sullair Compressor Unit Function

Cooling and Lubrication System Function

Compressor Discharge System Function

Control System Function

Detailed explanation of the WS Controller's operation across different pressure modes.

Installation

Compressor Mounting Procedures

Guidelines for establishing a suitable foundation and mounting the compressor securely.

Ventilation and Cooling Requirements

Instructions for ensuring adequate ventilation and cooling air flow for the compressor.

Service Air Piping Installation

Fluid Level Check at Installation

Electrical Preparation and Checks

Requirements for electrical connections, grounding, and pre-start checks.

Motor Rotation Direction Check

Procedure to verify correct motor rotation direction before compressor startup.

Fan Motor Rotation Check

WS Controller

WS Controller Layout Overview

Controller Keypad Operation

LCD Display Information

Explanation of compressor status, fault messages, and setting adjustments on the LCD display.

WS Controller LED Indicators

Maintenance

Daily Operation Checks

2000-Hour Maintenance Schedule

Specific maintenance tasks recommended every 2000 hours of operation.

Fluid Maintenance Procedures

Fluid Filter Maintenance

Procedure for replacing the fluid filter element based on controller indication or usage.

Air Filter Maintenance

Separator Maintenance

Pressure Regulator Adjustment

Water Condensate Drain Maintenance

Control Line Strainer Cleaning

Troubleshooting Introduction

Troubleshooting Guide

Guide to diagnosing and resolving common compressor symptoms and probable causes.

Sullair 1809e Specifications

General IconGeneral
Model1809e
Free Air Delivery180 CFM
Maximum Pressure125 psi
Voltage460V
Phase3
CFM Range180 CFM
TypeRotary Screw Air Compressor
