Summer 27903Z - Latch Assembly Variations; Gate Operating Instructions

Pull back
thumb pad,
lift and
open Gate.
Operating Instructions
REMOVING THE GATE:
OPENING THE GATE:
CLOSING THE GATE:
Push Gate until
handle engages &
locks in Top and
Bottom Latch Catch.
Push Gate until
handle engages &
locks in Top and
Bottom Latch Catch.
There should be
1/16" (1.6 mm) space
between the Gate and
the Bottom Latch
Catch.
1/16"
(1.6 mm)
Banister to wall
Latch Assembly is identical to Hinge
Assembly. Choose which of the two
options best ts your needs.
Repeat
Assembly
Option A
Repeat
Assembly
Option B
Square Top
Banister
Wall
Mounted
3. Latch Assembly (cont.)
SAFETY
WARNING
If installing gate at top
of stairs, DO NOT mount
into wallboard.
IMPORTANT NOTE:
When mounting into any
wood (molding),
a pre-drilled hole is
required. Pre-drill a hole
in the wood, using an
1/8’ or 3mm drill bit
approximately1 inch
deep.
Banister
align!
bottom
top
align!
8
