Summit Pool Heat Pump - Service Analyzer Control

OWNER’S MANUAL
Service Analyzer Control
The control panel is factory set to display the temperature in Fahrenheit degrees.
13
Temperature
and parameter
display
Celsius or
Fahrenheit mode
Access to
parameters
To raise the desired
temperature or to
change parameters
To lower the desired
temperature or to
change parameters
Heating mode
Compressor ( )
or fan ( ) running
Heating mode
