Summit SFC-500 SERIES - Figure 12: Indicating Circuit - Class B or Style y Wiring; Figure 13: Indicating Circuit -Class a or Style Z Wiring

Field Wiring
22
Figure 12: Indicating Circuit – Class B or Style Y Wiring
Figure 13: Indicating Circuit –Class A or Style Z Wiring
- SIG 1 +
STYLE Y
WIRING
STYLE Y
WIRING
INDICATING
CIRCUIT - 1
INDICATING
CIRCUIT - 2
RLE TTAW 2/1 K9.3EBORTSLLEB
INDICATING
CIRCUIT #1
INDICATING
CIRCUIT #2
HORN
FIRE PANEL MAIN BOARD
- SIG 2 +
NOTE: WIRE INDICATING CIRCUITS # 3 AND #4 IN THE SAME WAY AS #1 AND #2
BELL
STROBE
HORN
+
-
STYLE Z
WIRING
STYLE Z
WIRING
INDICATING
CIRCUIT #1
INDICATING
CIRCUIT #2
INDICATING
CIRCUIT 1
INDICATING
CIRCUIT 2
2 MORE INDICATING
CIRCUITS NOT SHOWN
SOCA-204 CLASS A
CONVERTER MODULE
FIRE PANEL MAIN BOARD
BLK RED
BLK RED
-SIG1 OUT+- SIG2 OUT+
-SIG1 RET+-SIG2 RET+
+
-
SIG 1SIG 2
NOTE: WIRE INDICATING CIRCUITS # 3 AND #4 IN THE SAME WAY AS #1 AND #2
