Sun-Mar COMPACT - Excel;Excel Ne Explosion Diagram

EXCEL/EXCEL NE SPECIFICATIONS
EXCEL/EXCEL NE EXPLOSION DIAGRAM
1)
Toilet Seat
9)
Finishing Drawer
17)
Drum Screen
2)
Bowl Liner
10)
Footrest
18)
Bio
-
d
ru
m
™
3)
Front Cover
11)
Heater
Tray
(Ele
ctric)
19)
Shaft Assembly
4)
Handle
Swivel
12)
Hea
ting Element
(Electric)
20)
Ge
ar
5)
Drum Door
13)
Electric Box (Electric)
21)
Top
6)
Tank
14)
Thermostat Assembly
(Electri
c)
22)
4” (100mm
)In
let Pipe (NE)
7)
8)
Footrest Channel
Drum Locker
15)
16)
Safety Drain Assembly
Air I
ntake Vent
23)
Fan Assembly(Electric)
20
Toilet Maximum
Amps
Fan
Power
Heater
Power
Average
Power
EXCEL
(115V)
2.4 A 35 Req 260 W 125 W
EXCEL
(230V)
1.25 A 35 Req 265W 125 W
