1 Place the heated blanket/mattress pad on the bed with the label at the foot of the bed facing upward.
2 Connect the cord into the module at the bottom of the heated blanket/ mattress pad until the plastic
hinges click into place.
CAUTION: Cord must be COMPLETELY CONNECTED. A risk of fire could result from a loose connection.
3 Run the control cord on the floor under the bed. Do not sandwich cord between the mattress and box
spring. Avoid any tangling or pinching.
4 Plug power cord into a 110-120 volt wall outlet.
CAUTION: Do not use with generator power or inverter.
Control Placement:
• Dual Control for heated blanket or mattress pad – place primary control (label on back of
control) on the right side of the bed.
Heated Blanket, Mattress Pad and
Comforter Setup
See Control Features on page 8
for your individual control.
If there is a flashing light or your control displays
a flashing “F” , “F1” or “F2” see page 13.
• Single Control for heated blanket or mattress pad –
the control can be placed on either side of the bed.
STEP 1
Place on bed with
label at foot of bed
facing out
STEP 2
Connect the Control
Cord connector and
module securely
STEP
3
Run Control Cord
under the bed
STEP
4
Plug Power Cord
into wall
STEP 1
Place on bed with
label at foot of bed
facing out
STEP 2
Connect the Control
Cord connector and
module securely
STEP
3
Run Control Cord
under the bed
STEP
4
Plug Power Cord
into wall
