Sunbeam PU8000 - Figure

13
Care and Cleaning (continued)
5. Lift the grind cartridge away from the
grinder base, see figure 10.
6. Clean the grind cartridge and bottom burr
using the burr cleaning brush (located
under the grind spill tray), see figure 11.
7. Once both burrs are cleaned, return the
grind cartridge to the grinder base so that
the arrow on the side of the grind cartridge
is aligned with the ‘ALIGN’ arrow on the
grinder base. Turn clockwise until the arrow
on the grind adjustment collar is aligned
with ‘LOCK’ arrow and the ‘RELEASE’
button pops out.
Figure 11
Figure 10
