5. Chart of the device
5.1 Antenna：Antenna connector
5.2 DC 12V：Power input.
5.3 LAN：LAN port: It also can be DHCP Server.
5.4 WAN: RJ-45 internet connector，standard RJ-45 socket，connect to
HUB.
5.5 PWR (Power LED)：Light up when power is normal.
5.5 VoIP1：An indicator light of VoIP1
5.6 VoIP2：An indicator light of VoIP2
5.8 LINK Indicator：Light up when network is connected.
5.1
5.2 5.3 5.4 5.5 5.6 5.7 5.8
