9.17 Marin Massage/Waterfall Selector Diagram
Massage Selector Operation
Rotate Massage Selector 1 to divert water between designated jet
groups.
Massage Selectors (1)
• Massage Selector #1 controls pump #2.
Waterfall Selector (2)
• Waterfall Selector #2 controls circulation pump output to waterfall.
Continuously Powered Jets (3)
• Jets #3 are always on when jets pump #1 is running.
