Sundown Audio SALT-4 - Full Range Digital 4-Channel Wiring

Wired Remote Control
( Optional )
SALT-200.4, SALT-300.4 & SALT-500.4 - 3 Channel Speaker Connection Mode.
8~4ohms
HEADUNIT
FULL RANGE DIGITAL 4CH INPUT CONNECTION
FULL RANGE DIGITAL 4CH SPEAKER CONNECTION
MidRange
/Bass
Passive
Tweeter
8
