60
LMC-341F
TYPICAL RECOMMENDED SPARES LIST
FLUID END ITEMS
TYPICAL CLASS
(2)
LOC NO. OPTION
(1)
PART NUMBER DESCRIPTION 1 2
3
3
A
LL BO03AD07DB3 BOLT, IMPELLER 0 1
1
87
A
A
LL GK01AW01 GASKET, THERMAL 1 1
2
2
A
LL JM01AD87DD6800 IMPELLER,COMPRESSOR 0 0
1
50
A
DS,TS SL01AD16DD SLEEVE, LOWER 0 1
1
50B,50 DS,TS,SS SL01AD02DD SLEEVE, UPPER 0 1
1
51C DS,TS RJ09AD20RE RING, MATING, UPPER 1 1
2
60
A
SS,TS SE04AD21F SEAL, LOWER 1 1
2
60B DS,TS SE04AD21F SEAL, UPPER 1 1
2
--
A
LL RKORC311FUC O-RING 1 2
2
NOTES:
(1) Options: SS = Single Seal, DS = Double Seal, TS = Tandem Seal,
(2) Class 1 = Minimum recommended spare parts necessary to perform a startup and inspection
of a new unit.
Class 2 = Minimum recommended spare parts necessary to cover 1-2 years of normal service
Class 3 = Minimum recommended spare parts necessary for critical service, or units that will be
installed in remote locations.
(3) * Items are alternate items, and should be purchased according to user's preference
(seal kits are available for mechanical seals only).
Revised 10/3/00
