LMC-341F

TYPICAL RECOMMENDED SPARES LIST

GEARBOX ITEMS

TYPICAL CLASS

(2)

LOC NO. OPTION

(1)

PART NUMBER DESCRIPTION 1 2 3

A160 WS PU04AW02 PUMP, LUBE, REVERSIBLE 0 1 1

115 ALL 20-314 SEAL, ASSY, INPUT 1 1 1

-- AA 22-141 FILTER, OIL, HILCO 2 6 6

125C ALL 21-108 BEARING, INPUT, UPPER 0 1 1

125D ALL 21-108 BEARING, INPUT, LOWER 0 1 1

151A ALL BT20AD0860B BEARING, HIGH SPEED, LOWER 0 0 1

151B ALL BT20AD0860B BEARING, HIGH SPEED, UPPER 0 0 1

151C ALL BE09AY02A BRG, JOURNAL, LOWER IDLER 0 0 1

151D ALL BE09AY01A BRG, JOURNAL, UPPER IDLER 0 0 1

155A AA WA05AA01320 WASHER, THRUST, LOWER 0 0 1

155B AA WA05AA01320 WASHER, THRUST, UPPER 0 0 1

51D ALL RJ09AA21SD RING, MATING 1 1 1

60C ALL SE04AA53A SEAL, ASSY, GEARBOX 1 1 1

936ZG ALL 14-057UC O-RING 2 4 4

936P ALL 14-055UC O-RING 2 4 4

936T ALL 14-324UC O-RING 2 4 4

936TQ ALL 14-324UC O-RING 2 4 4

936TT ALL 14-324UC O-RING 2 4 4

936Y ALL 14-322UC O-RING 2 4 4

936YA ALL 14-322UC O-RING 2 4 4

936ZF ALL 14-323UC O-RING 2 4 4

A130 ALL SH01AY05E1L0 SHAFT, ASSY, HIGH SPEED 0 1 1

NOTES:

(1) Options: WS = Wet Sump , AS = As Applicable

(2) Class 1 = Minimum recommended spare parts necessary to perform a startup and inspection

of a new unit.

Class 2 = Minimum recommended spare parts necessary to cover 1-2 years of normal service

Class 3 = Minimum recommended spare parts necessary for critical service, or units that will be

Installed in remote locations.

Revised 10/3/00
